Evaluating scalability of bias mitigation techniques on large language models
This project was made in a Practical Workshop course, aiming to recreate a research project over the span of 2 months. The choice of this subject was motivated by the recent explosion in popularity of large language models, which has highlighted inherent biases against certain demographics or cultures induced by training data. Not only does this shortcoming spread stereotypes and preconceived ideas, but data generated by LLMs is now being used to train new LLMs - which is obviously a dubious cycle. With this work, we hope to contribute to the existing research on the correction of these biases, which could lead to the development of more ethical and responsible models, as well as to highlight a problem that is easier to solve today than tomorrow.
As for any research project, we started with an extensive literature review. Current research presents not only techniques for mitigating biases, but also for evaluating them - a critical step for addressing them. However, we spotted a major limitation in existing works : the techniques presented were tested on relatively small LLMs such as BERT or GPT-2, but rarely on billion-parameter models. We decided to angle our research around replicating bias mitigation experiments that seemed relevant - as well as reproducible - on large language models with billions of parameters. This led to the definition of the following research question :
We selected Bloomz and Flan-T5 because smaller versions of the models were available on HuggingFace, with respectively 560 and 248 million parameters. Although this contradicts part of our question, it was necessary to address the hardware limitations we were facing. This restriction was the most hindering we faced, having large needs (enough GPU RAM to fit a whole LLM in order to fine-tune it) with very low resources, the most we had being free-tier Kaggle Notebooks containing two T4 GPUs. Both these models are also capable of following task instructions zero-shot, a requirement to fine-tune them.
To evaluate the bias in the models, we used two different types of metrics : three of them were provided by HuggingFace (Toxicity, HONEST, Regard), and three of them were our adaptations of metrics we found in the literature based on the StereoSet benchmark. StereoSet is a crowd-sourced dataset that captures four different types of biases. By prompting the model to select completions for sentences among offered ones - with some containing biases - we can calculate three scores representing not only the bias but also the general understanding of the model (Language Modeling Score, Stereotype Score, Idealized Context Association Test).
Finally, we needed a dataset to fine-tune the models. We selected the CrowS-Pairs dataset, which offers pairs of stereotyped and non-stereotyped sentences with the pairs usually differing on a single word that completely reverses the expected stereotype. Our approach involves either exposing the models to biased sentences or offering the sentences with a gap on the biased word, and then presenting the preferred responses as reference answers.
Summary of the workflow of our process.
Before fine-tuning, the FLAN-T5 family of models performed best in the StereoSet benchmark, showcasing superior reasoning abilities. However, the fine-tuning resulted in a decrease in overall performance, potentially due to the models not being specifically trained for rewriting sentences in a less offensive way. We experienced this problem with both models, struggling to prompt them in a way they were trained on. Additionally, we also encountered another phenomenon we learned about during our review of literature : catastrophic forgetting. This causes the models to completely forget their original training tasks after the fine-tuning. Existing research puts forward techniques such as freezing certain layers to mitigate this phenomenon, but those techniques were not reproducible. The HuggingFace metrics confirmed the decline in performance, with increased toxicity evaluations after fine-tuning. This increase also highlighted another limitation we read about, that states that reducing the capability of a model reduces its bias. This raises a question in the method we used : is the fine-tuning mitigating the bias or only reducing the model's capability.
While our results were not as conclusive as we anticipated, they offered valuable insights. Firstly, it is clear that using small-sized models had a significant impact on various aspects, from text generation to instruction comprehension. This often led to models generating new sentences instead of completing the given prompts as intended. Secondly, our main approach of fine-tuning aimed to shift the tendency of the models to use certain words. While it may be viable for an effective change in behavior, it is not sufficient for creating a properly debiased LLM. In fact, it may inadvertently introduce biases in the opposite direction of existing stereotypes, which is not desirable.
This work was my first insight in a research project. Being used to completing projects and having access to documentation to solve problems, the lack of existing solutions to our problems was frustrating. Additionally, the hardware constraints we faced forced us to use smaller - which often means worse when referring to LLMS - models, resulting in lackluster results to our research. However, this project allowed us to verify and validate theories that had been put forward by other researchers, as well as to do our part in making AI models more responsible. We hope that our contributions will help in this endeavor and give future works a better idea of the challenges they will have to face.
Reinforcement learning for a personalized news system recommending real-time scraped news
This project was made in a Practical Workshop course, aiming to create a complete product and fitting into a market in order to meet a user need. Being three students in AI and having never worked with reinforcement learning, it is quite naturally we chose to work on a tech news recommendation system. We wanted to ally the efficiency and source diversity of newsletters with the availability and "infinity" of news brought by websites like Google News, Apple News, etc. We worked on this project with the CRISP-DM methodology, that is summarized in the figure above.
Our data was constituted from various sources : Twitter API, Reddit API, GNews API and News API. We then preprocessed the data before merging them all and uploading them into a database hosted on the Microsoft Azure service. All of these tasks were automated, which allowed a continuous flow of news into the database while the older ones were removed to ensure relevancy.
We decided to use a Deep Q Network to recommend the news, a model that is part of the family of value-based algorithms : it tries to maximise its long term reward. In our case, since we positioned our product as a gateway to access news, we were trying to maximise the number of news the user clicked on (i.e. was interested in). The final product consisted in a simple purified UI, which recommended batches of 10 news. When the user disconnected or asked for a new batch, the news that were ignored got a penalty, while the others got a reward. This way, by using the interface on a long-term basis, the users got recommended news similar to those they usually clicked on.
Screenshot of the final product
The main problem we faced with the data was to ensure its quality, especially with the social networks' APIs. Since the goal was to have an automated routine, manually checking the data was not a possibility, and the tools we had to filter data were sometimes insufficient to prevent "random" posts from entering our system (for example, a meme getting a lot of traction posted on Twitter with "#ChatGPT"). However, the part we struggled the most with was evaluating our model. The DQN trying to maximize long-term reward, we had to set its parameters to make it as greedy as possible to try and see immediate reactions to our actions, which is not the way it is intended to use - making it tough to evaluate the model.
This course being oriented as a "professional" project, it was very different to other projects I have done during my education. Not only did we work with the CRISP-DM methodology, we also assessed the current market for our product, developed a marketing strategy, etc. The tradeoff to spending some time on the business aspect of things was sacrificing the technical part : we only got an overview of reinforcement learning. However, it was great practising how to market a product and how to use professional tools like Microsoft Azure as it is a rare opportunity in technical studies.
Deep neural network for a lane-following system predicting the steering angle based on NVIDIA's PilotNet paper
PilotNet is a project first issued by NVIDIA in 2016 in the paper "End to End Learning for Self-Driving Cars". It is a neural network trained on data coming from cameras located on top of a car, associated with the corresponding steering wheel angle. The goal of the network is simply to predict the correct steering angle for the camera picture. While this project obviously has limitations - there is no notion of speed although that impacts the angle in real life - it is a first step towards autonomous driving, and was a great project for my Deep Learning course at UQAC.
I found two datasets - containing over 45 thousand images - thanks to links provided on the following GitHub : SullyChen/driving-datasets. I also did not have to think too hard to build a model : the original NVIDIA paper contained the exact model they used, which was perfect for my first real deep learning project. It is a deep convolutional neural network that is described in the image below.
PilotNet model created by NVIDIA
The main issues I faced during this project was training the model. The large amount of data, combined with the important number of trainable variables as well as the difficulty of the task made it challenging to perform this task while working with little to no budget. I however had a Google Cloud free trial, and I invested every last penny of it using TensorFlow Cloud, a Google Cloud Platform service allowing users to deploy deep learning models on cloud infrastructures, while accessing and outputting data from a bucket. With this service, I had access to 4 Tesla P100 GPUs - which took me as far as 8 epochs in the model training.
Although this training was very disappointing - I was initially planning on training the model on at least 20 epochs - the model still performed relatively well. To have a more visual way of evaluating the results (seeing the image and having the value of the angle is tough to interpret), I created a simple loop : loading an image, predicting the angle, then showing the image with a steering wheel image rotated to the predicted angle. By looping as fast as the model prediction allows it, you get a realistic view of what's going on - and can easily evaluate the quality of the results. Using this method, I was able to see that my model performed relatively well, although it had a tendency to steer left.
Example of the visualization of the problem at hand
Seeing the results - especially the "weird" angles sometimes predicted - naturally made me wonder why the model took such decisions. To try and limit this black box effect, I implemented saliency maps. They are a graphical representation of the zones of the image having the most influence on the output of a CNN. I used the Blur Integrated Gradients method to compute the model's saliency map for each image and, using the same visualization process as described before, I was able to see the elements on which the model was basing itself to make its prediction.
Saliency map plotted as heatmap over the original image. The prediction is quite good, the model is basing itself on the white lines either side of the car, the middle separator and the trees/sky in the background.
There are many ways to improve this project and take it to the next level, I unfortunately did not have the time to pursue them since I struggled so much with the training. I would have loved to incorporate the speed of the vehicle as well as other basic car information to make the project more realistic, or even hook it up to a driving environment simulator and see my car progress in a simulated city. However, this was one of my favorite projects so far : not only was I challenged by the complexity of training a model of this caliber, it also had a fun dimension in the plotting of the results and seeing the saliency maps for the bad predictions. Working on the PilotNet project allowed me to get more familiar with TensorFlow but also to get a first experience on a reality of the deep learning process I wasn't familiar yet : deploying models on cloud infrastructures.
Project including budget management and team management using the Agile method, based on the development of Machine Learning models able to predict solar panel production on the French territory
Video presentation of the project (auto-generated English subtitles work !)
This project was made in the Data Science Project course at the Université de Technologie de Belfort-Montbéliard. We acted as a mini Scrum Team in a company, managing all aspects of the project including human resources, budget, planning, business model, specifications, communication, and the development process. Our efforts spanned over a period of 6 months, resulting in the creation of a complete software application. As a result of our hard work and dedication, we were given the opportunity to present our project to a startup incubator.
This idea came about after finding a report from UK Power Networks - an electricity distribution system operator covering part of England - following a feed-in tariff scheme introduced by the UK to encourage electricity generation using small-scale systems (≤5MW). The associated dataset included over 25 thousand days of collected data in domestic sites containing solar panels, adding up to over 171 million measurements. The data wasn't perfect as it contained some missing values making some measurements unusable, but we still had enough data after cleaning it to stick with this idea.
Before moving forward, we tested the plausibility of our project to predict the electrical production of solar panels from weather data by implementing a simple Linear Regression model and plotting its predictions.
Comparison between average values predicted by a Linear Regression model and real ones in the test set
Although these results were far from perfect, they were good for a basic unoptimized model, so it encouraged us to keep going, having seen the potential of the project. We then tested 12 different models on the dataset to see which class of models would perform better, and found out that models based on a Random Forest outperformed the others.
Comparison of the performance of the differest tested models
We then optimized all of the promising models by searching for their optimal hyperparameters using grid searches. Finally, we decided to use the CatBoost model as it is the one that performed with the most consistency, as our tests using the Root Mean Squared Error showed.
To showcase this model, we build a product around it, focused on France. We used React and Django to develop a website aiming to sell our model as a subscription, following the trendy shift of business models from product to services. Using weather APIs such as OpenWeather and Solcast and a Leaflet map, we only require that the user selects his location on the map to predict the estimated production, financial gain and other features.
Sequence diagram of the website for a prediction
This project was a very eye-opening experience as it allowed us to envision the development of a product, a business model, and more generally, the opportunity to integrate artificial intelligence into a realistic setting. Exchanging with non-profit organizations to collect solar panel data and meeting with a startup incubator and thinking about taking this project to the next step was an amazing way to get a glimpse of what being an entrepreneur requires.
Multivariate human activity classification from time-series sensor data
This project was carried out as part of the "Special Topics" course at UQAC, which allows a student to deepen their knowledge in a chosen field. In my case, the overall objective of this course was to introduce concepts and knowledge in the processing of time series in order to perform classification. The dataset I chose comes from the paper "The Opportunity challenge: A benchmark database for on-body sensor-based activity recognition," published in 2013. It aims to classify daily activities such as opening a fridge, drinking coffee, etc. The data was collected from hundreds of sensors in various scenarios with different subjects. Four different subjects performed six runs : one planned run called "Drill" and five free runs called "ADL".
The first step was to explore the data and to check its conformity. To do so, I plotted the data from each sensor as a time series to look for any inconsistency. For example, using only the data from the drill runs, I verified that the curves of the different subjects were consistent, as all four subjects performed the same activities in the same order.
Accelerometer data plotted as time series and Kernel Density Estimate
To use the data, I first had to process it by applying a couple of operations. After the traditional machine learning pre-processing, I converted the data to reduce the size of the dataset. The sensors collecting the data every 33 milliseconds, I converted the dataset by summarizing chunks of 30 values (i.e. every 1 second) with statistics for every sensor over that second. I extracted 7 values from each sensor : mean, maximum, minimum, standard deviation, median, skewness and kurtosis. I also only kept the data that had only one activity on the chunk, which represented a loss of less than 15% of the data and greatly simplified the problem.
In order to get a better idea of which type of models would perform the best on the task at hand, I tried some simple machine learning models belonging to different families of algorithms. With the results I got, I decided to go forward with the Random Forest and XGBoost algorithms, leaving aside the K-Nearest Neighbors, Gaussian Naive-Bayes, Decision Tree and Gradient Boosted Trees algorithms.
This project aiming to discover techniques and tools, I didn't want to spend a lot of time running Grid Searches and to try to optimize those models, I simply ran some tests on the main parameters of the algorithms to find the best compromises between performance and execution time. For example, on the graph below, we can see that a depth of 20 is enough for the Random Forest to get decent performance.
In order to further simplify the data and to make the execution times faster, I used different techniques of feature selection. The one that worked the best was the Feature Selector library, which got rid of over 75% of features for the Random Forest, and even more than that for XGBoost. The accuracy of the models actually improved with less features, demonstrating the curse of dimensionality phenomenon.
Since I had explored some classical machine learning models, I also wanted to look into some deep learning models. However, it became quite clear that those models were too complicated for my problem. Indeed, the Bi-Directional Long Short-Term Memory, 1-Dimensional and Multi-Headed Convolutional Neural Networks that I tried faced a major issue : they took a lot of training to understand the problem. In a relatively easy problem such as the one at hand, the trade-off between performance and execution time is way better with machine learning than with deep learning.
To be sure whether my implementation of those algorithms was the problem, I also used the Sktime library, with a CNNClassifier and a RocketClassifier instance. This library requires the data to be in a certain format, and then automatically extracts the information it needs. With both models, I got the same results as in my own implementations : the classifiers need a lot of training to get decent results - especially since I only ran computations on CPU.
This project was made over a span of 2 months, which limited my methodology to be exploration-oriented and not result-oriented. Furthermore, the dataset used is a benchmark for multivariate human activity classification, which can be used in different ways. With the way I processed it, it contains high data imbalance, which made it "easy" for the algorithms to get decent results by always classifying the predominant class. However, this project allowed me to get a better understanding of how to deal with time series data, as well as to think about the opposition between deep learning and classical machine learning algorithms.
Minimax algorithm with performance improvements using the UCI protocol
The engine was developed as part of a course on AI at Université du Québec à Chicoutimi. The aim was to make an Java engine capable of playing every move in under 1 second, and being able to communicate with the Universal Chess Interface protocol to play in a graphical interface. In order to focus on the algorithm, we used the chesslib library, providiing us list of legal moves for a position, bitboards, and other useful tools.
To search the game tree, we implemented Minimax, an algorithm used in game theory that aims to minimize the loss or degradation of a game situation. It involves "virtually" evolving a starting situation and imagining all possible responses from the opposing player at a given depth (5 for our chess engine). The best outcome is then chosen and taken back to the root, which determines the next move to be made. In the game of chess, the tree of possibilities grows quickly because of the many possibilities available each turn. Therefore, much of the work in this area involves trying to reduce the search field and optimize the code in order to reduce execution time.
Paired with Minimax, we also used a Quiescence Search to finish exploring unstable leaf nodes, to help solve the horizon effect. This problem arises in the complex decision trees of games like chess or go, where the tree is too wide and deep to explore completely, so we must limit our exploration. However, this has the disadvantage of making us blind to responses that we could have studied in the next iteration. One way to solve this problem is to detect if a leaf of the tree is "unstable," and perform additional search to determine the true value of that leaf. In our case, an unstable leaf is one where the previous move was a capture. For these leaves, we perform a quiescence search and further explore the branch, considering only captures in order to limit the branching factor. Essentially, if we finish the MiniMax tree exploration with a capture by a queen, this additional search ensures that the queen will not be captured immediately by a piece covering the one we captured.
In order to be able to explore that much under a second, we implemented numerous optimizations. The first obvious one is Alpha-Bêta pruning, ensuring that the branches of the tree that do not improve the player's gain value are pruned.
Alpha-Bêta pruning relying on comparisons, it is possible to increase the number of pruned branches (and therefore improve performance) by evaluating promising positions as early as possible : this is called Move Ordering. First, the Most Valuable Victim/Least Valuable Attacker (MVV/LVA) table is used to analyze capturing moves, which assigns a value based on the piece that is capturing and the piece that is being captured. Therefore, if the victim is a Queen, the value returned will be higher than if the victim is a Pawn. Then, after considering the victim, we also sort based on the attacker. It is better to capture a piece with a Pawn than with a Rook, because often the capturing piece is endangered. The MVV/LVA table handles capturing moves ordering, while non-capturing moves are ordered using two heuristics, the Killer Move and the History Moves. The first one is based on the concept of the Killer Move, which is a move that causes pruning. Specifically, if a move threatens a Queen, it will cause significant pruning in the tree because all moves that do not move or protect the threatened queen will be eliminated. The second one is the most effective method for sorting our non-capturing moves because it takes into account the success of moves in the past. Each time a non-capturing move is successful in causing pruning, its value is increased. This simple concept places moves that have previously caused cutoffs (and so are likely to do that again) forward.
Another way to reduce the game tree search without pruning is to use Transposition Tables. This is an optimization that is not reset between calls to MiniMax. Essentially, if a position is explored, we store a representation of this position - called a Zobrist Hash, which allows us to efficiently store a position and its information - and the value associated with it. This way, for each position explored during MiniMax, we check beforehand if we do not already know the position and therefore its value, thus avoiding costly exploration.
Finally, we also used three other pruning methods. Futility pruning is applied when there is a depth of 3 or less remaining in the search and helps to prune positions that have no potential. For each depth, a value is associated, and if the evaluation of the position added to this value is less than alpha - or if the evaluation of the position subtracted from this value is greater than beta - we consider that this position cannot improve the best move : it can therefore be pruned. Null Move pruning is based on a rather amusing and humiliating concept : if we play a "blank" move - that is, we do not play and therefore virtually leave two moves to the opponent - and the latter still suffers a significant enough deficit to cause alpha-beta pruning, then we can prune all of this part of the tree. Delta pruning is applied only to the Quiescence Search and works roughly the same way as futility pruning. Delta is given a fixed value, and if the evaluation of a position to which delta is added does not improve the best value, we consider that this branch is not worth exploring. This helps to avoid exploring unnecessary branches of the tree, which often happens in the Quiescence Search, which aims to explore all captures.
The other part of exploring the game tree that takes time is to evaluate each position. To do so efficiently, we decided to implement a "lazy" evaluation for positions that only needed an approximation of the exact score, and to do an in-depth evaluation when an exact score was required. The lazy evaluation only consists of an evaluation of the material both sides have.
Values given to different pieces based on the "Centipawn" principle
In order to weight the values associated with the pieces showed above, we used PSTs (Piece-Square Tables) for each piece. These are arrays containing 64 entries, one for each square on the chessboard. For each square, a value - bonus or penalty - is therefore defined that will be added to the value of the piece. In order to be as exhaustive as possible, we used two PSTs per piece, one for the midgame and one for the endgame. We can therefore see in the figure opposite, representing the PST of the knight for the midgame, that positions centered on the chessboard, which therefore control more squares, are valued, and that positions that are very off-center are penalized.
Piece Square Table for the Knight in midgame
To separate positions with the same pieces, we also implemented two other evaluations to complete the material one. The first one concerns the position of the pawns : we slightly penalize doubled pawns, blocked pawns and isolated pawns. In this way, we do not modify the evaluation enough to influence the material, but with equal material we favor more advantageous positions. The other one consists of checking which color "controls" each square on the chessboard : if Whites have more pieces that can go to this square, we will consider that Whites control this square. It is somewhat a modified Static Exchange Evaluator, which concerns all squares.
Finally, since boards cannot be evaluated the same depending on which game phase we are in, our evaluation function was inspired by the principle of Tapered Evaluation, which consists of modifying the evaluation according to the progress of the game. We therefore applied weights to the three types of evaluations that we implement depending on the phase of the game we are in.
This assignment allowed us to discover the principle of Minimax and its multiple optimizations, which are popular for adversarial exploration. Even if we had already implemented it during our university course, it was very formative to start from this already known base and push it so that it reaches its full potential. We therefore explored several optimization techniques, whether in algorithms or even in pure programming (moderate use of loops, numerous rereads of the code to avoid duplicating actions, etc). This work, complex but rewarding, pushed us to go beyond the work required to create an engine that we are very proud to have designed and that represents a great success for us.
Optimization methods for the Random Forest, especially with significant work on data and on the parallelizations of the algorithm
This project was made as part of a course on Machine Learning for Big Data. We explored some of the optimization methods applied to the Random Forest algorithm that were presented in the research work of Jianguo Chen, Kenli Li, Zhuo Tang, Kashif Bilal, Shui Yu, Chuliang Weng and Keqin Li, who presented a parallelized version of the Random Forest in a Spark cloud environment. These researchers present their work on this parallelized Random Forest in an article entitled "A Parallel Random Forest Algorithm for Big Data in a Spark Cloud Computing Environment", published in October 2018. This project was made to understand the challenges of machine learning in a context of Big Data and to present solutions that can address this problem.
The dataset we used came from Kaggle and can be found with this link. It consists of data concerning the NIFTY 100, a well-diversified 100 companies index reflecting overall market conditions in India. We chose this dataset not only for its concrete and serious data but also its size : it is just under 70 GB with 66 features. The data was not ready for use, so we had to make a couple of operations on it. First, cleaning it up, then creating the label our Random Forest was going to predict. We also created weights to balance the model, as well as do some dimensionnality reduction with Principal Component Analysis to make the data easier to use.
Cumulative variance in regard to the number of features, in order to keep over 99% of information
To do our tests, we first used a local Spark environment using a machine with 20 cores, 16GB of RAM and 3.6GHz. However, we quickly realized it was not enough to handle data this size, so we used a cloud solution : Digital Ocean Droplets with 16GB of RAM and 8 AMD vCPUs. With this configuration, we were able to test different models on our data, and see the difference between them.
Comparison of the execution time and F-measure of the different studied models
With this, we were able to come to two conclusions. First, with the similar execution times of the Random Forest and the Decision Tree, we were able to demonstrate the power of parallelization, as the Forest is made of many single trees - but they still run in about the same time. Secondly, we tested the pyspark GBTClassifier model, a model that uses Gradient Boosted Trees. This model, which appeared more recently than the others, works according to a simple principle : we train a standard decision tree, then train multiple models to predict and correct the error of the first model. Since this model also uses an ensemble of trees and is supposed to be more performant than the RandomForestClassifier, we thought it was advisable to try it. However, despite an execution time of 16h 27m 40s, we were forced to stop it before it finished training. This is due to the fact that boosting is a technique that sequentially combines models and does not favor parallelization.
Concerning data parallelization, we also tried running a scikit-learn model on the data. However, the transformation of the training dataframe into a Pandas dataframe could not be executed. Indeed, when performing this task, we try to retrieve the data distributed on the cluster in order to centralize it on a core, which is not robust enough to support such a large amount of data.
Execution time of the different models in regard to dataset size
This assignment was meant to compare different learning techniques, and several conclusions were drawn. First, as seen in the article, parallelization should be applied to both tasks and data. Our comparison between PySpark and scikit-learn showed the importance of distributing data when working with larger scales, as the non-distributed method was simply unable to handle such large data sets. Second, we saw the impact of parallelization of calculations in our comparison with Gradient Boosted Trees. While the Random Forest, which uses the bagging principle, is easily parallelizable to the point that its execution time is almost equal to that of a Decision Tree, the sequential boosting technique is not well suited (at least in its basic form) for distribution and therefore for such large data sets. The sequential boosting has a nearly linear curve and therefore does not scale well to larger sizes, while the parallelized Random Forest has a curve that increases very little and only changes slightly, demonstrating its resistance to scaling. With these two points in mind, we were able to conclude that PySpark's distributed system is crucial and that the simplicity and effectiveness of the Random Forest allows it to maintain a reasonable timeline.
Experiments with GANs and Conditional GANs to create artworks from specific artistic currents
I chose to do this project in the computer vision course while at UQAC mainly because I had never worked with generative models, but also because they require lots of data and computing power. This forced me to use cloud computing services and get out of my comfort zone - and step into a more "realistic" deep learning environment. A more general objective of the project was also to develop and stick to a methodology, and mine was to take things step by step and gradually increase the difficulty of the tasks I was attempting.
Although my final goal was to make a conditional Generative Adversarial Network, I started by "just" developing a GAN from an artwork dataset. I used common architectures of Deep Convolutional GAN for my generator and discriminator, which are summarized below.
Architecture of the generator
Architecture of the discriminator
This worked fairly well, but the dataset contained very unbalanced classes, which hindered greatly its ability to generate artworks from different styles. For that reason, I switched to another bigger dataset, that I found on Kaggle. Although it suffered from unbalanced data as well, the least populated classes contained well over 1000 paintings, which I deemed enough to get decent results. Using the same architecture as described earlier, the training of the GAN generated this GIF :
I then divided my journey to building a CGAN in three major steps : first, building a CGAN generating artworks from only two classes with one channel (i.e. a grayscale image), then adding color, and finally all the classes. Training a CGAN being way longer than training a GAN, this step-by-step process allowed me to test different configurations while minimizing the wait time between versions.
This strategy allowed me to single out problems with my CGAN implementation, especially one induced by batch normalization. Given that this process normalizes the activations of a layer on a mini-batch of inputs, the standardization operation interferes with the storage of conditional information in normalizing the discriminator entries on the batch. This caused my resulting generated images to be limited to noise, and did not allow for the discriminator to train. Handling this problem - and others - allowed me to get better results, and more convincing training processes.
Training curves of the CGAN
However, I still was not satisfied with the conditional information. Although the problems were probably also caused by insufficient training and too few data, I emphasized the information by scaling it up as a "fourth" channel using a fully connected layer in the final code to ensure my implementation was not the problem. The results I obtained were some of the best I got with conditional GANs, but were nowhere near what I obtained with the basic Generative Adversarial Networks, an example of which you can see at the top of this page.
Example of results of the CGAN for the Baroque style (left) and Rococo style (right)
Although this project did not deliver results-wise, it allowed me to get a grip of GANs, and continued to make myself more comfortable with Deep Learning. Furthermore, the size of the data and model parameters made me use GPUs and TPUs for the training through services like Google Colab and Kaggle Notebooks, which was fairly new to me. The fact that training an iteration of the model took over 8 hours also forced me to really apply my methodology and think ahead before running code, which is something I often overlook, preferring to try and retry.
Reproduction of experiments aiming to demonstrate the scalability of a distributed Decision Tree in Pyspark
This project is based on the work presented by Vasile Purdil et Stefan-Gheorghe Pentiuc in their paper named “MRTree-A Scalable MapReduce Algorithm for Building Decision Trees”, published in 2014. The aim of the project was to demonstrate the scalability of the distributed version of the Decision Tree model, which I did in a local Spark environment using a machine with 20 cores, 16GB of RAM and 3.6GHz.
The data I used is the same as in the article, it is a dataset containing unclean data describing characteristics of persons in order to predict their class of income. It is available following this link. Once the data cleaned, the dataset contained 14 features and 45222 records, and had a size of about 6 Mo. I then converted all the values into numerical ones to create a Resilient Distributed Dataset of LabeledPoints to feed to the Decision Tree.
To demonstrate the importance of distribution, I needed a bigger dataset so I scaled it up by duplicating it up to 50 times. This way, I was able to get the graph below, confirming what the scientific paper described.
Evolution of the Decision Tree's training time and dataset size in terms of the scaling factor
I also carried out different tests during this project, like for example focusing on the variation of the execution time when changing the number of cores in the local cluster from 4 to 20. As exepected, we can see that the time decreases with the addition of cores.
This project was a great way to get familiar with PySpark and different distributed notions, also comparing them to their scikit-learn equivalents in the process. Re-demonstrating the improvements put forward by the article really shows the importance of distribution in Big Data scenarios and was a first step towards working in more "realistic" environments, as opposed to working locally on a laptop.
Implementation of the DFS and MinMax algorithms in order to develop an Artificial Intelligence able to play the card game "Love Letter"
This project was an exciting opportunity to discover the fundamental concepts of artificial intelligence and work on algorithms covered in class. We made the choice to work on Love Letter, a popular zero sum card game, meaning that the gain of one player is balanced by the loss of the other player, making it an ideal candidate for AI development.
The artificial intelligence we set out to develop needed to be able to act like a player :
To create our AI, we implemented two key algorithms: DFS (depth-first search) and Negamax. These algorithms allowed our AI to explore the possible moves in the game and make decisions based on the likely outcomes. In particular, the Negamax algorithm, a simplified version of the MinMax algorithm that is based on the principle of a zero-sum game, allowed us to efficiently evaluate the potential value of each move, helping our AI make intelligent decisions even in the face of uncertainty. The logic behind the algorithm is simple : player A, who is searching the game tree, will always try to maximize their moves and minimize those of their opponent. Although there are not many rounds in a game of Love Letter (a maximum of 8 rounds), the Negamax algorithm requires too many calculations to predict all the possible outcomes of the game in cases where the players have exhausted the deck and the victory is decided by the highest card. In order to reduce the number of states generated by the artificial intelligence - and reduce the time of reflection - we decided to implement alpha-beta pruning, which keeps only the promising branches of the tree based on previously visited nodes.
Although we didn't have time to make an interface for playing the game - it is only playable in console - we did make a prototype of what we would've done with more time. It is accessible with the following link.
Overall, this project was a great learning experience for me. It not only helped me solidify my understanding of AI fundamentals, but also sparked my interest in the field and made me eager to explore more advanced topics in the future. Working on this project was a challenging and rewarding experience, and I am proud of the AI we developed.
Development of a smart vacuum agent living in a mansion, picking up dust and jewels with intelligent pathing
This project was made as part of a course on AI and was done to create an smart agent with an internal state based on the Belief-Desire-Intention model, progressing in a updating environment. Both the agent and the environment are executed in parallel in two different threads.
The vacuum moves in an environment represented by a two-dimensional map containing cells, each of which can contain dust, jewels, or a vacuum. The initial state of the map is determined by randomly generating objects based on certain rates, and the map is then updated over time using different rates. The environment is partially observable, meaning that the agent's sensors do not give it access to the state of the environment at all times. It is also stochastic, meaning that the outcome of an action is not certain, and episodic, meaning that it is divided into a sequence of independent episodes. The agent's actions are limited to moving in one of four directions or performing no action, and its performance is measured by the number of steps taken and the number of objects cleaned up.
The agent is made up of sensors and effectors, as well as an internal state. The sensors, represented by the Sensor class, are the interface between the agent and the map. They provide the agent with information about the environment, such as the presence of jewels or dust and the location of the agent on the map. The effectors, represented by the Effector class, are the actions that the agent can take on the environment. They include functions like traveling to a specific location and performing a specific action on a cell. The internal state of the agent includes a list of intentions, metrics about its progress, and a copy of the map. It also has a boolean value indicating which exploration algorithm to use. The agent's mental state is based on the Belief-Desire-Intention model, which means it acts rationally and executes actions that maximize its performance based on its perception of the world and its knowledge. The agent's beliefs are based on the information it perceives from the environment and its own knowledge, and its desires are its motivation to act, with the ultimate goal of cleaning the map of all dust. The agent's intentions are the actions it plans to take to achieve its goals. His performance is defined by a formula taking into account the overall cleanness of the map, the battery used by the agent and giving penalties for the jewels it vaccumed.
We conducted a series of tests on the agent in order to determine its optimal learning frequency. The lower this frequency, it will have an optimized path for the dusts existing at the time of the creation of the path, but will miss out on the dusts that have spawned since then, with the environments running continuously in parallel. We conducted tests with exploration frequencies ranging from 1 to 5 actions, as well as an infinite frequency, in order to measure the importance of this parameter. We recorded the performance of the system at various intervals over different periods in order to obtain a representative measurement. We found that an exploration frequency of 1 resulted in a lot of hesitation on the part of the agent, while higher frequencies allowed it to be more efficient in cleaning the map.
The agent uses either the BFS or A* algorithms to search for the next action to take. Both algorithms are implemented in the Graph class and involve creating nodes for the trees and the agent's intentions, as well as building the solution from the goal node. The BFS algorithm expands each node by visiting all of its neighbors before visiting the neighbors of those neighbors, while the A* algorithm uses a heuristic function to prioritize nodes that are closer to the goal. Both algorithms also have a test for the goal and a method for building the solution from the goal node. The BFS algorithm has a high space complexity due to the large number of nodes that it generates, but it has a low time complexity due to its simple expansion process. The A* algorithm has a lower space complexity and a higher time complexity due to the more involved expansion process and use of the heuristic function.
This project made us create an agent made up of sensors, effectors, and an internal state, including a list of intentions and metrics about the agent's progress. The agent's mental state is based on the Belief-Desire-Intention model, which means it acts rationally and executes actions that maximize its performance based on its perception of the world and its knowledge. The agent uses either the BFS or A* algorithm to search for the next action to take.
These tools were the result of my work during my 6-month internship as an engineer assistant internship at Luxembourg Online
During my fourth year internship at the Université de Technologie de Belfort-Montbéliard, I had the opportunity to work at Luxembourg Online, a company located in the Grand Duchy of Luxembourg. I joined the software development team at this independent company, which has been a prominent presence in Luxembourg for over 25 years. While working on a module for managing recruitment, I solidified my web development skills (HTML, JavaScript, CSS, etc.) and also learned Luxembourg Online's proprietary language, OSL. I also participated in larger projects, gaining experience and confidence throughout my internship.
My primary task during this internship was developping a tool that would be added to the ERP to help with the recruitment process in the company, that lacked structure until then. The absence of a dedicated tool not only hindered the efficiency of the process, but also constituted a very time-consuming task for HR. The main objective of the recruitment module was the administrative management of applications, and thus to have not only a global vision of the applications in progress at a given time, but also a history of applications. It is essential to keep a record of applications as it can, for example, allow a candidate to be contacted again if the position they applied for is recruiting again.
Another major challenge was to develop a tool that met the needs of Luxembourg Online's HR while remaining sufficiently general to suit other companies using Luxembourg Online's ERP. Although the initial objectives were relatively modest, limited to the simple management of positions and applications, they became more ambitious as I became more familiar with the environment. In fact, the management of advertisements was later added, then the rating of candidates by targeted users, the management of interviews, and finally the addition of an automated email and notification system. As the supplement to be developed had no predecessor, the problem in determining the objectives was not "how to improve the existing tool", but rather "how to frame the recruitment process while making it easier for HR to reduce their workload".
Throughout my internship, I tried to put a focus on modernity and user interface. I was always allowed to develop a first version of my module as I saw fit, before reviewing it with my tutor or a long-time employee, familiar with the shop and responsible for validating the interfaces of additions to it. Of course, I was not given free rein : my module still had to fit in with the rest of the ERP and respect its graphic charter. In fact, the shop is a tool that has been in place for many years and I would describe its interface as "vintage", which meant I had to create similar elements. Similarly, there are ways of doing things that are deeply ingrained in the ERP as they are present in many supplements to which I had to conform, although I personally considered them less effective. In addition, one of the reasons I enjoyed web development was the freedom to do anything - whether visually with CSS or functionally with JavaScript - but when I had to set up something that already existed in the shop, my creativity and contribution were restricted. However, my constant proposals of modernization and improvement ideas bore fruit. Indeed, quite quickly - after a little less than two months in the company - my tutor considered that my way of seeing and representing things was innovative and constructive. I therefore had parallel missions to my module to carry out, such as the redesign of the company's agenda, the creation of a drag and drop area for files, or the design of the user interface of another module.
Gantt diagram of my time at Luxembourg Online
I am generally satisfied with the work I have done at Luxembourg Online and the skills I have acquired. Over the 23 weeks of my internship, I was able to carry out a project from start to finish independently, by defining a specification, working in collaboration with the main users to design a product that meets their needs, while ensuring a tool that is sufficiently general to be sold and exploited by any company. Concretely, this is a module for the ERP that is fully integrated into the latter and consists of 4 pages, allowing the management of applications, as well as open positions, published advertisements, and platforms receiving these advertisements. I also produced a tool that facilitates the download and handling of files within the ERP, which will be added to the company's style guide and will therefore be reused in other projects. Finally, I also designed a prototype to improve a crucial tool used daily in many services - the company's agenda, greatly facilitating its use by adding relevant and problem-specific features.
Development of a website regrouping and structuring the different tutorials related to the UTBM tools
The development of a website for UTBM to regroup their different tools was a complex and challenging project that required careful planning and attention to detail. The aim was to provide assistance and information on various computer services used within the educational institution, given a four-month timeframe and the freedom to use any technologies desired, with the requirement that the site be maintainable and developable by others in the future. The project focused on user interface design, but also required work on the back-end for the site to function properly.
After having understood the needs of the future users for this tool, we defined the architecture our website was going to have and made a prototype based on the architecture. This interactive mock-up of the web platform was designed to demonstrate the simplified functioning of the site to potential users and was intended to provide a realistic representation of the final product without requiring actual development work. It is accessible with the following link.
Concerning the database design, the initial design for the database included tables for categories, articles, and their contents. As the development of the site progressed and we gained more knowledge, we realized that the database architecture could be simplified. First, by using a MarkDown text editor for the descriptions of articles, which allowed us to eliminate some tables made superfluous. The final design for the database included tables for categories, articles, users, media files, settings, and logs, and included an admin user on the MySQL server.
We made several technical choices in the creation of the site. We used Figma to create prototypes and design systems, as it is lightweight, fast and allows for instant collaboration on files. For the front-end of the site, we considered multiple JavaScript frameworks including React JS, Angular JS, and Vue JS, as we wanted a modern, responsive framework that would ensure the website would look great and function smoothly on a wide range of devices. Ultimately, we chose React JS due to its ability to create interactive user interfaces, define simple views for each state of the application, and update graphical interface data as it changes in the database. We also used Gatsby JS, a static website generator, to improve the performance of the website in terms of loading and general functioning. For the back-end, we used Node.js, particularly the Express framework, and the GraphQL query language for the management of data. Finally, we chose MySQL for the database management system.
Throughout the project, we remained focused on achieving our goals and ensuring that the new design would be a success. We consistently tracked progress and made adjustments as needed to ensure that the final product met our high standards. In the end, the designed website that we handed over to UTBM was well-received by users. Overall, it was a challenging but rewarding project that demonstrated our ability to successfully tackle complex design challenges, as well as making us learn about the relationships between the different technologies we used. Finally, it was one of our first insights on how to organize large projects, and the time and effort required for project management, task allocation, and hierarchy in development.
Following a campaign of surveys within both students and employees of UTBM, re-design of the UI of the online work tool of UTBM "Moodle" to make it fit with the user needs
Our project to redesign the UI of UTBM's Moodle resources website was a comprehensive and thorough process that involved several key steps. It originated from our personal daily use of Moodle, we found the tool fonctional and well suited for the task, but not it's User Interface. This is why we focused our approach on user needs, and tried to rethink the UI around those needs in 4 steps.
The first phase was to create a survey to gather user needs and preferences - and assure ourselves everyone felt the need for a new UI - which we distributed to a large number of users. This allowed us to get a broad range of feedback that would inform the design process. As expected, a lot of featured features were only used by 25% of users a couple of times a month.
The second phase was to convene a panel of a dozen different users to discuss the results of the survey and provide further input and guidance. This panel was composed of users with a variety of backgrounds and experience levels, and their insights were invaluable in shaping the direction of the project.
In the third phase, we created a test version of the new Moodle design, incorporating the feedback from the survey and the panel. This allowed us to see how the design would work in practice and make any necessary adjustments.
Finally, we held another meeting with the panel to discuss the test version and get their feedback. Based on their comments and suggestions, we made further refinements to the design before presenting the final version to UTBM for consideration.
Overall, the project was a resounding success. UTBM was impressed by the thoroughness and professionalism of our process, and ultimately decided to implement our revamped version of Moodle as the official one. We are proud of the work we did and are confident that the new design will greatly improve the user experience for UTBM students and faculty.
